Input
Sensitivity: +1 dBu
for full output.
Input Impedance:
20 kohm.
Input Connectors:
1/4-inch TRS balanced phone jack, removable terminal block (2X650 and
2X110 only), male and female XLR.
Distortion:
<0.006% THD, 1 kHz, 1 dB below clip, 22 kHz measurement bandwidth.
Frequency Response:
20 Hz to 20 kHz, +0/–0.2 dB; <2 Hz to >120 kHz +0/–3 dB.
Controls:
Power switch, bridge mode switch, detented level controls (these may be
made tamper-proof).
Indicators:
AC Present, Operate, Signal, Bridge, Clip, Temp, Fault.
Protection
(microprocessor supervised): Over-temperature, DC on outputs, output stage
overload, inrush current surge, power fail and brownout.
Noise:
<–100 dB ref. full output 20 Hz to 20 kHz measurement bandwidth.
Slew Rate:
>50 V/microsecond.
Damping Factor:
>200 ref. 8 ohm.
Output Connectors:
Binding post and Speakon® on 2X650 and 2X1100, Binding post or Speakon®
options on 4X300.
AC Power:
230 volts AC nominal, 2200VA, all channels driven.
Dimensions:
89 mm (3.5 in.) x 460 mm (18.2 in.) x 483 (19 in.).
Weight:
11 kg (24 lbs.).
